Model Name

SVF22T-FIR7024

Image Device

1/2.9” 2.1 Mega-Pixel  CMOS Sensor

Total Pixels

2000(H) x 1225(V),2.48 Megapixel

Effective Pixels

1984(H) x 1092(V),2.16 Megapixel

TV System

NTSC / PAL

Video output

AHD or TVI or CVBS(1280H)

Synchronization

Internal

Resolution

AHD 1920 X 1080p (1080p / 25,30fps)

Sensitivity

0.1Lux  [0Lux with built-in 36 infrared LEDs]

S/N Ratio

More than 50dB

Shutter Speed

1/60(1/50), FLK, 1/240(1/200), 1/480(1/400),
1/1K, 1/2K, 1/5K, 1/10K, 1/50K

White Balance

2000 ~ 8000ºK Automatic tracking

Noise Reduction

DNR. Smart DNR

Lens

3.6mm

IR LED

24pcs of 850nm LED

Day & Night

True Day & Night (ICR)

Power  Supply

12VDC 500mA

Operating Condition

-20ºC~+60ºC / 10%~85%RH
